QHS CO2 Mixer, Drink Mixer For Carbonate Beverage / Soft Drink/
Energy Drink
product description
Beverage Co2 / Carbonated Drink Mixer (carbonated drinks mixer)is used for producing all
carbonated beverages (water, syrup, and CO2 mixing), for example lemon, coca cola, fruits juice
and so on. It is the main equipment in whole beverage production line. (Especially for middle and
higher standard beverage production).
Products Structure and Working Procedur
(1). CO2 tank, syrup tank, liquid level device, static mixing device, tank, electrical controlling
system, air providing tank, and necessary producing pipe and cleaning pipe including ball valve,
magnetism valve, check valve are composed this machine. (See photo 1: main structure)
(2). Main working Procedure
a. Cooling water→multi-grade pump→oxygenating CO2→volume control
b. Cooling syrup→multi-grade pump→syrup tank→volume control
(a and b → multi-grade pump→static mixing device→
c. CO2 air resource→filter and pressure reducing→ tank→filling machine
technical parameter
| MODEL | QHS-1500 | QHS-3000 | QHS-6000 | QHS-8000 | QHS-10000 |
| Production capacity (KG/H) | 1500 | 1500-3000 | 4000-6000 | 6000-8000 | 8000-10000 |
| Regulation range of sugar&water mxing ratio | 1:3-1:10 |
| Gas content (CO2:H2O volume ratio) | 2.5 | 3 |
| Mixing accuracy | ≤2% |
| Chilled water entrance temperature | 0～5℃ | 0～4℃ |
| Chilled water entrance pressure | 0.01～0.08MPa |
| Syrup entrance temperature | 2～8℃ |
| Syrup entrance pressure | 0.01～0.08MPa |
| Carbon Dioxide purity | >99.9% |
| Syrup tank working pressure | 0.01～0.09MPa |
| Storage tank working pressure | 0.2～0.5MPa |
| Motor total power (KW) | 1.1 | 3.5 | 5.1 | 8.5 | 11 |
| Dimension(mm) | 1030*1180*1930 | 1650*1300*2000 | 1900*1300*2250 | 3200*2100*2500 | 3800*2200*2750 |
| Weight(KG) | 600 | 1300 | 2000 | 2800 | 4800 |
product pictures
if have a furthur learn, we will provide you more helpful information...
